VFINE - High-Pressure Oil Free Air Compressor System For PET Stretch Blow Molding Machine
The VFINE high-pressure oil free air compressor system is an exceptional and cost-effective solution for your pet stretch blow molding machine needs. This system provides a reliable flow of clean, oil-free air that ensures high-quality bottle production. Designed with advanced technology to deliver optimal performance, this compressor system can withstand the rigorous demands of industrial applications. With its compact design, easy maintenance, and energy efficiency, the VFINE high-pressure oil free air compressor system is an excellent investment for any industrial facility.
5.0
Lubrication Style:
Oil-free
After-sales Service:
Includes
Warranty:
1year
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
After long-term exploration and hard work, Zhongshan Vfine Machinery Co., Ltd have launched Oil Less Free High Pressure for Pet Bottle Blow Blowing Molding Machine Screw Air Compressor System Systems Portable Pump Unit that lead the industry. After the Oil Less Free High Pressure for Pet Bottle Blow Blowing Molding Machine Screw Air Compressor System Systems Portable Pump Unit was launched, we received good feedback, and our customers believed that this type of product could meet their own needs. Zhongshan Vfine Machinery Co., Ltd will keep pace with the tide and focus on improving technologies, thereby creating and manufacturing products that better suit the needs of customers. We aim to lead the market trends one day.
| Cooling System | Water Cooling | Power Source | AC Power |
| Cylinder Position | Angular | Structure Type | Semi-Closed Type |
| Installation Type | Stationary Type | Type | Single Screw Compressor |
| Product | Air Compressor System | Transport Package | Wooden Box |
| Specification | 3package | Trademark | vfine |
| Origin | China Guangzhou | HS Code | 8414809090 |
| Production Capacity | 1000sets/Year | Package size per unit product | 190.00cm * 120.00cm * 160.00cm |
| Gross weight per unit product | 2400.000kg |
Product Description
Compressor System for Pet bottle Blowing Oil Free less screw type high pressure air
about vfine and chumful
![Oil Less Free High Pressure for Pet Bottle Blow Blowing Molding Machine Screw Air Compressor System Systems Portable Pump Unit]()
![Oil Less Free High Pressure for Pet Bottle Blow Blowing Molding Machine Screw Air Compressor System Systems Portable Pump Unit]()
![Oil Less Free High Pressure for Pet Bottle Blow Blowing Molding Machine Screw Air Compressor System Systems Portable Pump Unit]()
![Oil Less Free High Pressure for Pet Bottle Blow Blowing Molding Machine Screw Air Compressor System Systems Portable Pump Unit]()
Training: customers can send technician to vfine factory for 7-10 days training by buyers own charge
Delivery time: 30 days after confirmation of bottle designed and receipt of the down payment
Packing: Included the packing cost..
Guarantee: We promise that our goods are all new and not used. They're made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. The machine is guaranteed in 12months from the date of commissioning signed or 13months from bill of loading with the normal operation conditions and seller shall be in charge of installation of machine.
Installation: Vfine would send engineer to Any installation outside of China, but buyer shall pay traveling expenses, including but not limited to, air ticket fees, 3 star-level boarding lodging fees, and all expenses for seller engineers' trips, also buyer should be apply the visa for seller's engineers. Buyer need also pay the salary for engineer.
After sales
After checking, within the quality guarantee time, free offer wearing parts and offer other parts at the lowest price. In quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems. The cost of technician arrangement you could see the cost treatment method of technician.
After quality guarantee, we offer technology support and after sales service. Offer wearing parts and other spare parts at favorable price; after quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems.
Q&A
Q: is the air compressor system include the tank
A: yes, the system include complete unit, the air compressor, air tank, air dryer and air filters.
Q: is the air compressor system oil free
A: yes it is a oil free air compressor system
Zhongshan Vfine machinery Co ltd
Zhongshan Chumful machinery Co ltd
website: vfine88.en.made-in-china.com
about vfine and chumful
•Zhongshan chumful machinery co ltd is the one branch of Zhongshan Vfine machinery co ltd, which is a professional manufacturer of PET bottle blowing machines, that integrates the R&D, production, and sales. Since the development and design of the first generation linear automatic stretch blow molding machine, Vfine's technical team has focused in the PET market for 20 years. We've successfully supplied machines to many world-famous brands.
![Oil Less Free High Pressure for Pet Bottle Blow Blowing Molding Machine Screw Air Compressor System Systems Portable Pump Unit]()
| item | Description and suggestion |
| Air compressor Air pressure:4.0Mpa | Produce the high pressure air |
| tank Air pressure:4.0Mpa | Storage of the high pressure air, also as the buffer to cool the hot air; the water and dirt would be left in tank, so that to reduce load of air treatment system. |
| High pressure air dryer Air pressure:4.0Mpa | The oil and water within the compress air would be cooled to liquid status, the solid dirt together with the cold liquid will be exhausted out from the automatic drain, then the clean air can be provide to the production line. |
| Pre-filter Air pressure:4.0Mpa solid≤3 um Oil left≤5ppm | Clean the big solid dirt in the compress air. |
| Post filter Air pressure:4.0Mpa solid≤1 um Oil left≤1ppm | Clean the medium size solid dirt in the compress air |
| Precise filter Air pressure:4.0Mpa solid≤0.01 um Oil left≤0.01ppm | Clean all the solid dirt in the compress air |
| Carton filter Air pressure:4.0Mpa solid≤0.01 um Oil left≤0.003ppm | Clean the smell and dirt in the compress air |
Training: customers can send technician to vfine factory for 7-10 days training by buyers own charge
Delivery time: 30 days after confirmation of bottle designed and receipt of the down payment
Packing: Included the packing cost..
Guarantee: We promise that our goods are all new and not used. They're made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. The machine is guaranteed in 12months from the date of commissioning signed or 13months from bill of loading with the normal operation conditions and seller shall be in charge of installation of machine.
Installation: Vfine would send engineer to Any installation outside of China, but buyer shall pay traveling expenses, including but not limited to, air ticket fees, 3 star-level boarding lodging fees, and all expenses for seller engineers' trips, also buyer should be apply the visa for seller's engineers. Buyer need also pay the salary for engineer.
After sales
After checking, within the quality guarantee time, free offer wearing parts and offer other parts at the lowest price. In quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems. The cost of technician arrangement you could see the cost treatment method of technician.
After quality guarantee, we offer technology support and after sales service. Offer wearing parts and other spare parts at favorable price; after quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems.
Q&A
Q: is the air compressor system include the tank
A: yes, the system include complete unit, the air compressor, air tank, air dryer and air filters.
Q: is the air compressor system oil free
A: yes it is a oil free air compressor system
Zhongshan Vfine machinery Co ltd
Zhongshan Chumful machinery Co ltd
website: vfine88.en.made-in-china.com
